2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project

2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project
2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project

Large Image :  2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project

Product Details:
Place of Origin: Shanghai, China
Brand Name: VIBRA
Certification: ISO 9001:2015
Model Number: FV-150
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 16,000 to 23,000 USD
Packaging Details: 4.5 CBM
Delivery Time: 8-35 work days
Payment Terms: T/T, D/P, Western Union, MoneyGram
Supply Ability: 20 Set/Month
Detailed Product Description
Name: Small Pile Driver Feature: Made For Solar Panel Project Work
Vibration Frequency: 2800rpm Operation Pressure: 32 Mpa
Centrifugal Force: 172KN Max.Pile Length: 8m
Arm Weight: 260kg Hammer Weight: 1100kg
Excavator: 12-17 Ton Color: Blue/Yellow, Customized Color Available
Material: Steel, Core Materials Are All Imported Condition: New And Used Both Available
Type: Hydraulic Vibrating Hammer HS Code: 84301000
High Light:

2800rpm Mini Excavator Vibratory Hammer

,

Vibratory Hammer For Excavator

,

Solar Panel Construction Excavator Vibro Hammer

Description



Mini hydraulic pile driver is a unique product of our company. Its birth has filled in the industry gap: changed the history that small excavators cannot be refitted; solved the problem that small pile foundation cannot be mechanized construction.

This series of machines have made due contributions to the foundation construction of new rural reconstruction.

VIBRA vibrating pile hammer is utilizing its high frequency vibration to vibrate pile body with high-speed increase to pass the vertical vibration of mechanical produce to pile which prompting changes in the soil structure around the pile, strength decline. Soil around the piles become liquefaction to lessen frictional opposition between side of the pile and the soil. Then, at that point, utilizing the excavator down power, vibrating pile hammer and pile body weight to sink pile into the soil. When extricating piles, in the state of vibration to take out the pile by utilizing excavator lift power. Excitation power required by pile driving hardware are extensive controlled by site soil, soil condition, dampness content and sort of pile development.



Features



VIBRA hydraulic vibratory hammer is the vibratory driving piling equipment which is popular among a wide variety of foundation projects.Apart from driving and pulling elements such as sheet piles and pipes, vibratory hammers are also used for soil densifying or vertical drainage, especially suitable for municipal, bridges, cofferdam, building foundation, etc.

With advanced technology, vibratory hammer has advantages of low noise, high efficiency, non-pollution and non-damage to piles,etc.




Technical Parameter


Item FV-100 FV-150
Vibration Frequency (rpm) 2500 2800
Operation Pressure (Mpa) 30 32
Centrifugal Force (KN) 117 172
Max.Pile Length (m) 6 8
Arm (kg) 160 260
Hammer (kg) 850 1100
Excavator (T) 7-12 12-17




2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project 0

About Us


Ye Kun Construction Machinery Co., Ltd. is one specialized is engaged in the vibration sinking pile drawing machine equipment production, sale and service of technology-oriented enterprises, products mainly emerging a high-speed hydraulic pile drawing machine and peripheral accessories, equipment widely used in all kinds of foundation engineering construction.



After a short period of development, the company won the recognition of customers, and the annual sales growth doubled. Marketing the country with the VIBRA brand and export it. The company′s production of mini hydraulic pile driver, vibration hammer and other products quality has reached the advanced level of the industry.



2800rpm Mini Excavator Pile Driver For Solar Panel Construction Project 1



FAQ



Q: How long is the warranty period ?



A: The warranty period is 12 months from the date of completion of installation, the mainframe and key components, except for wearing parts.



Q: What is the MOQ ?



A: 1 set is available.



Q: What's the payment method ?



A: We accept T/T and D/P payment.



Q: What is the delivery time ?



A: The delivery time is generally 7-35 days, and arrive at Shanghai Port. Shipping time should be considered overseas.



Q: Can I have our LOGO on the machine ?



A: Of course you can.



Q: How is your product quality ?



A: Our equipment is strictly implemented in accordance with the technical standards of "Technical Conditions for Pile Driver Enterprises".



Q: Can I be your dealer ?



A: Welcome to become our dealer, and we are looking forward to further developing into a regional general agent and strategic partner like you with lofty ideals!



Q: How To Order?



A:
1. Please tell us the model with quantity and other requirement which you needed.
2. We issue the Proforma Invoice to you after confirmed the price and other details.
3. We arrange the order production upon receipt of confirmed PI and your deposit or original L/C.
4. After the goods is ready to ship, we will inform you the shipment date and other informations by email at the same time.
5. We will help to track your goods until you receive them safely.
