Side Grip Pile Driver – Low Headroom Operation Capability & Full 360 Degree Continuous Rotation for 32‑40T Excavators

The SV-400 is a heavy‑duty Side grip pile driver Made In China, engineered for 32‑40 ton excavators to perform in the most demanding low‑clearance and narrow‑space construction environments – factory retrofits, bridge underpinning, urban drainage, and underground parking extensions. Its low headroom operation capability – using both side clamp (465 kN) and bottom clamp (520 kN) – allows pile driving and extraction in vertical clearances as low as 3.8 metres. As a full 360 degree continuous rotation pile driver, it provides unlimited slewing without hose twisting, plus ±30° bidirectional tilt, eliminating the need to reposition the excavator on congested job sites. The compact structure confined spaces design keeps overall dimensions tight (1400×1315×3056 mm), enabling access through standard industrial doorways and between pillars spaced 3.5 metres apart. The high-flow merging valve unit ensures the hammer receives the full 280‑360 L/min flow required for its 656 kN centrifugal force, even when the excavator’s individual pump output is moderate. This combination makes the SV-400 the ideal choice for contractors in Southeast Asia, India, and Russia building bridge abutments, factory extensions, port facilities, and flood defence walls.

1. Side grip pile driver Made In China
The SV-400 is a proven Side grip pile driver Made In China, trusted by customers worldwide for its reliability, power, and ease of installation. It mounts onto 32‑40 ton excavators with minimal modification – typically 2‑3 hours for first fit, then 30 minutes for changeover. The side grip design allows the hammer to work alongside existing structures without needing a dedicated leader or crane.

2. Low headroom operation capability
Conventional piling rigs cannot work under low bridges or inside basements. The SV-400’s low headroom operation capability solves this problem by using a bottom clamp that grips the pile below the hammer’s main body. You can drive and extract piles in clearances as low as 3.8 metres – perfect for indoor piling, under flyovers, or beneath power lines.

3. Full 360 degree continuous rotation
Unlike hammers limited to 180° or 270°, the SV-400 offers full 360 degree continuous rotation with a hydraulic rotary union that allows unlimited slewing without hose twisting. Combined with ±30° side tilt, you can position piles at any angle, drive slanted retaining walls, or extract twisted sheet piles – all without moving the excavator. This saves hours of repositioning time on crowded sites.

4. Compact structure confined spaces
With dimensions of only 1400mm (L) × 1315mm (W) × 3056mm (H) and a weight of 3870 kg, the compact structure confined spaces engineering allows the SV-400 to fit through standard factory doorways, between columns, and inside shipping containers. This compactness also reduces transport costs – multiple units per container to remote sites in Siberia or island nations.

5. High-flow merging valve unit
The SV-400 requires 280‑360 L/min to deliver its full 656 kN centrifugal force. The high-flow merging valve unit combines two separate auxiliary circuits from the excavator into one high‑flow stream, ensuring consistent power even on machines with lower individual pump flow (e.g., 160+160 L/min). This integrated valve also provides two‑stage vibration control: first stage for soft soils, second stage (merged flow) for hard layers. It requires no external plumbing – just connect and work.

Southeast Asia (dense cities, low bridges, flood walls)

• Low headroom operation capability – drive sheet piles under elevated MRT tracks, low flyovers, and inside basement car parks.

• Full 360 degree continuous rotation – reposition piles without moving the excavator on narrow streets in Bangkok, Jakarta, Manila.

• Compact structure – fits through tight alleyways and standard industrial doorways.

India (bridge rehabilitation, metro projects, mixed excavator fleets)

• High-flow merging valve unit – compatible with older 32‑40 ton excavators (JCB, Sany, Komatsu) that have moderate auxiliary flow.

• Side grip pile driver Made In China – proven quality at competitive cost, reducing capital expenditure.

• 360° continuous rotation – speeds up sheet pile interlocking for bridge abutments and cofferdams.

Russia (extreme cold, remote sites, low‑clearance industrial plants)

• Reliable down to -30°C. Low headroom allows piling inside factory buildings without roof removal.

• Compact structure – reduces transport costs to Siberia; more units per container.

• High-flow merging valve maintains hydraulic power even with cold, thick oil – second stage boosts force when needed.

• U‑type and Z‑type steel sheet piles

• H‑beams (up to 400 mm flange)

• Circular pipe piles (up to 800 mm diameter)

• Replaceable clamp jaws – change in under 10 minutes

Q1: What is the minimum headroom for the SV-400?
A: With low headroom operation capability using the bottom clamp, you can work in clearances as low as 3.8 metres.

Q2: Can the SV-400 rotate continuously without hose damage?
A: Yes. As a full 360 degree continuous rotation pile driver, it features a hydraulic rotary union that allows unlimited rotation – no twisting, no hose fatigue.

Q3: My excavator has only 240 L/min total flow. Can it run the SV-400?
A: Yes – the high-flow merging valve unit combines two circuits (e.g., 120+120 L/min) to reach 240 L/min. For full 656 kN force, we recommend 280‑360 L/min, but the hammer will still perform at reduced power in lower flow.

Q4: What does “compact structure confined spaces” mean on site?
A: The SV-400 is only 1.315 m wide and 3.056 m tall. It passes through standard industrial doorways and works between pillars spaced 3.5‑4 metres apart.

Q5: How does the two‑stage vibration work?
A: First stage uses single pump flow for normal soils. Second stage activates the high-flow merging valve unit to boost excitation force for hard layers – all controlled from the cab.

Q6: Spare parts availability?
A: We stock wear parts (clamp jaws, seals, hoses, bearings) in Singapore (SE Asia), Mumbai (India), and Moscow (Russia). Delivery 3‑5 working days.
