Bore Drilling High Torque Chain Cutters For Improving Soil

Place of Origin CHINA
Brand Name VIBRA YEKUN
Certification ISO 9001:2015
Model Number CMD 10000
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details 10 CBM
Delivery Time 15-45 days
Payment Terms T/T, D/P, Western Union, MoneyGram, L/C, D/A
Supply Ability 5 sets/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name CMD Series Chain Cutters Feature High Torque
Excavator 50 ~ 80 Ton Power 220 Kw
Mix Width 500~600 Mm Mixing Depth 1500~10000 Mm
Length Of Cutter 3700~12200 Mm Color Blue/Yellow/Red/White, Customized Color Available
High Light

Bore Drilling Machine Chain Cutters

,

Improving Soil Chain Cutters

,

High Torque Underground Boring Machine

Leave a Message
Product Description

Designed Chain cutters for improving the soil by adding cement and binder to the soil while cutting



VIBRA YEKUN recent development CMD series chain cutters are designed to improve the soil by adding cement and binder to the soil while cutting. Different concentration of cement and binder can be used to achieve the required load-bearing capacity. The resulting stable, non-cracking soil-cement structure is freeze-resistant and waterproof, depending on the binder used in the slurry, and meets high levels of stability and watertightness. The CMD series chain cutters are made up of a specially designed, highly wear-resistant chain plate, pick block and pick teeth. Contact us to explore our new invention so that your business becomes more profitable!



Mixing and Infusion Equipment



Upper mixing

When the weight shows the sum of the weight of water and the weight of cement in the ratio, close the winch and let the upper mixer mix again for 2 minutes, then you can open the valve to put all the liquid into the lower mixer and use it.



Down mixing

The slurry pump draws the slurry from the lower mixing tank and transports it to the cutter.



Work Motivation

The CMD chain cutters are driven by two high-torque hydraulic motors plus planetary reducer for maximum power, with a theoretical output torque of 80,000Nm.



Working Principle



The CMD chain cutters are designed to improve the soil by adding cement and binder to the soil while cutting. Different concentrations of cement and binder can be used to achieve the required load-bearing capacity. The resulting stable, non-cracking soil-cement structure is freeze-resistant and waterproof, depending on the binder used in the slurry, and meets high levels of stability and watertightness.



Advantages:

  • In conjunction with the irrigation equipment, the soil can be restored and the non-load-bearing soil can be cured in place to load-bearing soil without the need to remove large amounts of soil, saving the cost of soil transportation.
  • Extremely low vibration, low impact on the surrounding environment.
  • Suitable for the construction of dam embankment soil stabilization that meets environmental requirements.
  • Extremely low construction time and high construction efficiency.
  • Deep soil consolidation, up to 10 meters deep.
  • The cures soil is extremely resistant to natural forces and chemical attack.

Technical parameter



Parameter Unit CMD5000 CMD10000
Recommended Excavator weights T 35~50 50~80
Power rating kw 130 220
Mix width mm 400~500 500~600
Mixing Depth mm 1000~5000 1500~10000
Recommended oil flow rate l/min 300~350 350~500
Maximum oil flow l/min 350 600
Cutting head diameter mm 1100 1100
Length of cutter mm 3200~7200 3700~12200
Cutting machine weight kg 6182 10082
For each additional meter of length kg 600 750
Theoretical output torque Nm 40000 80000





FAQ



Q: Are you a manufacturer?



A: Yes, we have been in this field for more than 12 years, our factory is in Suzhou and you are welcome to visit our unit anytime during working hour period,



Q: Who is your main customer?



A: Our customers are spreading all over the China with some abroad countries as well namely from New Zealand, Malaysia, Indonesia and many more are joining in the list. Brands like XCMG, SANY, Zoomlion, Caterpillar and Hyundai are our valuable customers.



Q: How long is the warranty period ?



A: The warranty period is 12 months from the date of completion of installation, the mainframe and key components, except for wearing parts.



Q: What is the MOQ ?



A: 1 set is available.



Q: What's the payment method ?



A: We accept T/T and D/P payment.



Q: What is the delivery time ?



A: The delivery time is generally 7-35 days, and arrive at Shanghai Port. Shipping time should be considered overseas.



Q: Can I have our LOGO on the machine ?



A: Of course you can.



Q: How is your product quality ?



A: Our equipment is strictly implemented in accordance with the technical standards of "Technical Conditions for Pile Driver Enterprises".



Q: Can I be your dealer ?



A: Welcome to become our dealer, and we are looking forward to further developing into a regional general agent and strategic partner like you with lofty ideals!
