Hydraulic Sheet Pile Driver - 535 KN Force & 18m Depth For Excavator Multi-Pile Works

VIBRA PCF - 450 Hydraulic Vibrating Pile Driver is a flagship large - scale foundation equipment of Shanghai Yekun Construction Machinery Co., Ltd., which was founded in 2009. It is specially designed for large excavators (47 - 55 tons) and stands out with 535 KN centrifugal force and 18 - meter maximum pile length. This pile driver relies on high - frequency vibration to liquefy surrounding soil, thus realizing efficient sheet pile driving and pulling. It is widely used in municipal engineering, bridges, cofferdams, building foundations and other large - scale infrastructure projects.

The product is driven by the excavator's hydraulic system. Its hydraulic motor drives two eccentric shafts to rotate at high speed in opposite directions. The horizontal forces cancel each other out, and the vertical forces superimpose to generate pure vertical vibration. This working mode can minimize the friction between the pile and the soil, and ensure stable operation even in complex geological conditions. It is a reliable choice for large - scale piling projects.

1. Powerful Piling Performance: With 535 KN strong centrifugal force and 3300 rpm vibration frequency, it can easily cope with large - scale sheet pile driving tasks and break through special geological barriers.
2. 18 - Meter Deep Piling Capacity: The maximum pile length can reach 18 meters, which fully meets the depth requirements of large - scale foundation projects and provides strong support for deep foundation construction.
3. Large Excavator Compatibility: It is perfectly matched with 47 - 55 ton excavators of any brand. Only by replacing the chuck, it can meet different construction needs, with strong versatility.
4. 180° Flexible Clamping: According to the sheet pile placement direction and site conditions, it can clamp or lower the sheet pile through 180° positive and negative rotation, adapting to complex construction layouts.
5. Low - Noise & Environmental Protection: Equipped with a rubber sheath, it can effectively reduce noise and vibration. The operation is quiet, will not damage nearby buildings, and conforms to environmental protection standards.

1. Multi - Pile Type Adaptability: It can drive and pull steel sheet piles, cement piles, steel rail piles, iron plates, H - steel and other types of piles, eliminating the need for multiple specialized equipment.
2. Efficient & Labor - Saving Operation: It can quickly switch working modes, and requires less force for pile pulling compared with traditional systems. The short working cycle greatly improves construction efficiency.
3. High - Quality Core Components: The control system adopts an imported integrated control valve, which can independently control each action and is convenient for maintenance and inspection. The hydraulic motor is small in size and light in weight, but has high power and speed output.
4. Cost - Saving Design: It uses the excavator's hydraulic system without additional driving devices, which saves fuel and transportation costs. At the same time, the lightweight design also enhances the flexibility of on - site application.
5. Pile & Site Protection: It will not damage the top and bottom of steel pipe piles, steel sheet piles and other piles, and can work safely near buildings without causing structural damage to the buildings.

Q1: What is the warranty period of this pile driver?

Q2: What is the minimum order quantity (MOQ)?

Q3: What payment methods are accepted?

Q4: Can we customize the logo on the machine?

Q5: How to ensure the product quality?

Q6: Is it easy to operate this pile driver?

Shanghai Yekun Construction Machinery Co., Ltd. was founded in 2009. It is a professional enterprise engaged in the manufacture, sale and service of hydraulic vibrating pile drivers. The company takes high - speed hydraulic vibrating pile drivers and their components as its main products, which are widely used in the infrastructure and construction industries.

We focus on product quality and keep up with the latest industrial technology. Our mini hydraulic vibrating pile drivers lead the industry trend, and medium and large - sized products are also highly recognized by customers. The company has a young, enthusiastic and professional team, and has hired foreign professionals as technical advisors. We also actively cooperate with engineering machinery factories and construction companies to jointly develop more functional professional equipment.

Adhering to the core values of "client as priority, quality as first concern, management as foundation", we are committed to becoming the most professional and comprehensive hydraulic vibrating pile driver manufacturer and service supplier in the industry.
