Sheet Hydraulic Pile Driver High Strength Vibro Hammer

Sheet Hydraulic Pile Driver High Strength Vibro Hammer
Sheet Hydraulic Pile Driver High Strength Vibro Hammer

Large Image :  Sheet Hydraulic Pile Driver High Strength Vibro Hammer

Product Details:
Place of Origin: Shanghai, China
Brand Name: VIBRA
Certification: ISO 9001:2015
Model Number: FV-280
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 20000 to 26000 USD
Packaging Details: 5 CBM
Delivery Time: 7-35 days
Payment Terms: L/C, T/T, D/P
Supply Ability: 30 set/month
Detailed Product Description
Name: High Strength Feature: High Performance
Arm Weight: 500kg Operation Pressure: 32Mpa
Hammer Weight: 1900kg Vibration Frequency: 2800rpm
Centrifugal Force: 335KN Excavator: 20-30T
Material: Steel, Core Materials Are All Imported Color: Light Green, Customized Color Available
HS Code: 84301000 Condition: New And Used Both Available
High Light:

Sheet Pile Hydraulic Vibrating Hammer

,

High Strength Vibro Hammer Pile Driver

,

Vibro Hammer Hydraulic Sheet Pile Driver

About Us



YeKun Construction Machinery Co., Ltd. is one specialized is engaged in the vibration sinking pile drawing machine equipment production, sale and service of technology-oriented enterprises, products mainly emerging a high-speed hydraulic pile drawing machine and peripheral accessories, equipment widely used in all kinds of foundation engineering construction.



Description



VIBRA vibrating pile hammer is utilizing its high frequency vibration to vibrate pile body with high-speed increase to pass the vertical vibration of mechanical produce to pile which prompting changes in the soil structure around the pile, strength decline. Soil around the piles become liquefaction to lessen frictional opposition between side of the pile and the soil. Then, at that point, utilizing the excavator down power, vibrating pile hammer and pile body weight to sink pile into the soil. When extricating piles, in the state of vibration to take out the pile by utilizing excavator lift power. Excitation power required by pile driving hardware are extensive controlled by site soil, soil condition, dampness content and sort of pile development.





Sheet Hydraulic Pile Driver High Strength Vibro Hammer 0



Technical Parameter



Item FV-250 FV-280 FV-300 FV-330 FV-350L FV-350 FV-400
Vibration Frequency (rpm) 2500 2800 3200 3200 3200 3200 3200
Operation Pressure (Mpa) 30 32 32 32 32 32 32
Centrifugal Force (KN) 265 335 350 372 435 455 485
Max.Pile Length (m) 10 12 12 12 15 15 18
Arm Weight (kg) 500 500 670 670 670 750 750
Hammer Weight (kg) 1700 1900 2100 2300 2400 2600 2700
Excavator (T) 20-30 20-30 30-35 33-40 35-40 40-45 45-60



Sheet Hydraulic Pile Driver High Strength Vibro Hammer 1





Sheet Hydraulic Pile Driver High Strength Vibro Hammer 2



FAQ



Q: How long is the warranty period ?



A: The warranty period is 12 months from the date of completion of installation, the mainframe and key components, except for wearing parts.



Q: What is the MOQ ?



A: 1 set is available.



Q: What's the payment method ?



A: We accept T/T and D/P payment.



Q: What is the delivery time ?



A: The delivery time is generally 7-35 days, and arrive at Shanghai Port. Shipping time should be considered overseas.



Q: Can I have our LOGO on the machine ?



A: Of course you can.



Q: How is your product quality ?



A: Our equipment is strictly implemented in accordance with the technical standards of "Technical Conditions for Pile Driver Enterprises".



Q: Can I be your dealer ?



A: Welcome to become our dealer, and we are looking forward to further developing into a regional general agent and strategic partner like you with lofty ideals!



Q: How To Order?



A:
1. Please tell us the model with quantity and other requirement which you needed.
2. We issue the Proforma Invoice to you after confirmed the price and other details.
3. We arrange the order production upon receipt of confirmed PI and your deposit or original L/C.
4. After the goods is ready to ship, we will inform you the shipment date and other informations by email at the same time.
5. We will help to track your goods until you receive them safely.
