45-60T Hydraulic Pile Driver For Excavators , Hydraulic Pile Driving Machine
|Name||Hydraulic Pile Driving Machine||Operation Pressure||32Mpa|
|Arm Weight||750kg||Hammer Weight||2700kg|
|Centrifugal Force||485 Kn||Excavator||45~60 Ton|
hydraulic pile driving machine,
hydraulic impact hammer pile driver
Low Noise Hydraulic Pile Driver Applied To Various Working Environments
1. Low Energy Consumption
2. High Efficiency
3. High Reliability
4. Convenience in dismantling,transportation and maintenance
5. Systemization and maximization of our products
6. Flexibility in designing
- Pile driving steel sheet pile, cement pile, steel rail pile, iron plate, H steel
- Quick converting operation; Applied to various working environments.
- Compared to other systems, less force required for pile pulling
- Not damage the top or bottom of steel pipe pile, steel plate pile and steel rail pile.
- Not damage the building even often work near it.
- Adopted Rubber sheath to reduce noise and vibration, the operation is quiet and the working period is short; It is helpful to overcome environmental problems.
- According to the placement direction of sheet pile and site conditions, the sheet pile can be clamped or lowered by positive and negative rotation of 180 °. The vibration frequency can be adjusted by two levels, and the two-level double pumps are combined to greatly increase the excitation force.
- Hydraulic motor has small volume and light weight, but it can output high power and high speed.
- Vibration frequency can be adjusted by variable pump. It can be used in excavator operation of any brand, and can meet different work requirements only after changing chucks.
|Vibration Frequency (rpm)||2500||2800||3200||3200||3200||3200||3200|
|Operation Pressure (Mpa)||30||32||32||32||32||32||32|
|Centrifugal Force (KN)||265||335||350||372||435||455||485|
|Max.Pile Length (m)||10||12||12||12||15||15||18|
|Arm Weight (kg)||500||500||670||670||670||750||750|
|Hammer Weight (kg)||1700||1900||2100||2300||2400||2600||2700|
