4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking

  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
  • 4-18 Module Hydraulic Pile Breaker for 20-30T Excavator with 400-2500mm Pile Breaking Diameter Range and for Pile Breaking
Place of Origin CHINA
Brand Name VIBRA
Certification ISO 9001:2015
Model Number SP-800
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 6 CBM
Delivery Time 5-20 days
Payment Terms L/C,T/T,Western Union
Supply Ability 50 sets/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Highlight

20 Ton Excavator Hydraulic Pile Breaker

,

4 Module Hydraulic Pile Breaker
Leave a Message
Product Description
Product parameters:
Maximum pressure of drill rod 800KN
Maximum pressure of a single cylinder 80T
Tonnage of supporting engineering machinery ≥20T
Maximum stroke of hydraulic cylinder 330mm
Drill rod diameter 110mm
Single module weight 330 kg
Maximum hydraulic cylinder pressure 33.5 MPa
Pile breaking height ≤ 500 mm
Single module dimensions 1015 x 865 x 410 mm
Number of modules(PCS) 4 8 9 10 11 12 13 14 15 16 17 18
Total weight(KG) 1400 2800 3150 3500 3850 4200 4550 4900 5250 5600 5950 6300
Pile breaking diameter range(MM) 400-700 750-900 800-1050 1000-1200 1200-1360 1360-1535 1500-1700 1700-1865 1865-2025 2000-2200 2200-2360 2300-2500
Applicable excavator tonnage   20-30T 30-40T/hydraulic system
