Heavy-Duty Pile Driver - Excavator Mounted, 12M+ Depth & Strong Geological Adaptability

VIBRA hydraulic vibro hammer pile driver is engineered for sheet piling work over 12 meters depth in construction projects, compatible with 6–60 ton excavators of leading global brands including Caterpillar, Volvo, Hyundai, Hitachi, XCMG, SANY, Zoomlion and Doosan. Unlike electric vibratory hammers, this hydraulic-driven system shares core structural traits (power unit, pile clamps, connection hoses) while delivering superior adaptability. It supports driving piles up to 24 meters long, handles diverse pile types, and comes with full-matching accessories for easy installation, fast piling speed and long-lasting performance, earning wide acclaim from global clients.

1. Multi-Pile Compatibility
   Capable of driving steel sheet piles, cement piles, steel rail piles, iron plates and H-beams, meeting diverse foundation construction needs.
2. Flexible Operation Design
   Enables 180° clockwise and counterclockwise rotation for pile clamping or lowering, adapting to different sheet pile placement directions and site conditions.
3. Two-Stage Vibration Frequency Control
   The second-stage vibration adopts double-pump confluence technology, which greatly increases excitation force to conquer special geological environments.
4. Integrated Imported Control System
   Equipped with imported integrated control valves, each operational action can be controlled independently, facilitating maintenance and inspection.
5. Compact & Energy-Saving Structure
   Mini and lightweight design ensures flexible application; it utilizes the excavator’s hydraulic system without the need for an additional power unit, reducing fuel and transportation costs.
6. Easy to Master
   Operators with basic excavator operation experience can proficiently operate the equipment after simple training.

1. Gentle Pile Handling
   Does not damage the top or bottom of steel pipe piles, steel sheet piles and steel rail piles, ensuring pile integrity and construction quality.
2. Low-Impact & Eco-Friendly Operation
   Adopts rubber sheaths to reduce noise and vibration, enabling quiet construction with short working periods. It can work near existing buildings without causing damage, solving environmental and safety concerns.
3. Efficient Pile Driving & Pulling
   Requires less force for pile pulling compared to other systems; high-frequency vibration liquefies surrounding soil to reduce friction, accelerating piling efficiency.
4. Strong Environmental Adaptability
   Supports quick conversion between different working modes, suitable for various construction environments including complex geological sites.

The hydraulic vibro hammer pile driver utilizes high-frequency vibration generated by the excavator’s hydraulic motor. The motor drives two eccentric shafts to rotate at high speed in opposite directions: horizontal forces cancel each other out to eliminate lateral vibration, while vertical forces superimpose to produce strong vertical-frequency vibration. This vibration is transmitted to the pile, liquefying the surrounding soil and breaking its structure to reduce friction, allowing the excavator to smoothly drive or drill the pile into the ground.
