Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction

  • Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
  • Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
  • Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
  • Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
  • Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
Place of Origin Shanghai, China
Brand Name VIBRA
Certification ISO 9001:2015
Model Number FV-350
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 7 CBM
Delivery Time 7-35 days
Payment Terms T/T
Supply Ability 15 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Solar Pile Driving Machine Feature High Performance
Arm Weight 750kg Operation Pressure 32Mpa
Hammer Weight 2600 Kg Vibration Frequency 3200 Rpm
Centrifugal Force 455 KN Excavator 40~45 T
Maximum Piling Depth 15 Meter (for Soft Soil It Can Be More Than 20 Meter) Color Blue/Yellow/Red/White, Customized Color Available
Material Steel, Core Materials Are All Imported HS Code 8430100000
Highlight

12 Meter Vibrating Pile Driver

,

Concrete Vibrating Pile Driver

,

Building Hydraulic Pile Driver
Leave a Message
Product Description
Heavy-Duty Pile Driver Ideal for 12m Concrete Sheet Pile Construction
Product Description

The VIBRA Hydraulic Vibrating Pile Driver is engineered for precision driving of concrete sheet piles up to 12 meters in height. Featuring an automatic clamping system that eliminates structural damage to piles, this robust machine delivers exceptional performance in high-storage building projects. By maintaining perfect hammer-pile alignment and transferring energy efficiently, it significantly reduces manpower costs and project timelines while ensuring superior pile integrity.

Keywords
  • Hydraulic Pile Driver
  • Vibrating Pile Driver
  • Concrete Pile Driver
  • Sheet Pile Driver
  • 12-Meter Pile Driver
  • Automatic Clamp Pile Driver
  • Construction Pile Driver
Technical Parameters
Model Centrifugal Force Max Pile Length Frequency Suitable Excavator
FV-280 335 KN 12 m 2800 rpm 20-30 T
FV-300 350 KN 12 m 3200 rpm 30-35 T
FV-330 372 KN 12 m 3200 rpm 33-40 T
FV-350 455 KN 15 m 3200 rpm 40-45 T
Key Features
  • Automatic Clamping System: Ensures perfect alignment and prevents structural damage to piles
  • Dual-Stage Vibration Control: Allows force adjustment for different soil conditions
  • Integrated Control Valve: Enables independent action control for easier maintenance
  • Compact & Lightweight Design: Provides exceptional mobility and setup flexibility
  • Excavator-Powered Operation: Utilizes existing hydraulic systems to reduce fuel costs
Competitive Advantages
  • Damage-Free Operation: Automatic cement sheet clamp protects pile integrity during driving
  • Reduced Labor Costs: Automated system minimizes manual intervention requirements
  • Faster Project Completion: Efficient energy transfer accelerates driving speed
  • Proven Performance: Successfully deployed in high-storage building projects worldwide
  • Multi-Brand Compatibility: Works seamlessly with leading excavator brands including XCMG
Working Principle

The pile driver utilizes high-frequency vibration generated by hydraulic motors to liquefy surrounding soil structures, significantly reducing ground friction. Two eccentric axes rotating in opposite directions create powerful vertical vibrations that enable smooth pile penetration while horizontal forces cancel each other to maintain stability.

Frequently Asked Questions

Q: How does the automatic clamping system benefit my project?

A: It ensures perfect hammer-pile alignment, prevents structural damage to concrete sheets, reduces manpower requirements, and accelerates project timelines.

Q: What is the maximum pile length your equipment can handle?

A: Our FV-350 model can drive piles up to 15 meters, while several other models are specifically optimized for 12-meter concrete sheet piles.

Q: Are you the actual manufacturer?

A: Yes, we have over 12 years of manufacturing experience with our factory located in Suzhou, maintaining strict quality control throughout production.

Q: What kind of excavator is needed to operate your pile driver?

A: Our models are compatible with excavators ranging from 20-60 tons, with specific models optimized for different weight classes as shown in our technical parameters.

Q: What is your warranty policy?

A: We provide a 12-month warranty covering mainframe and key components, with wearing parts excluded under standard terms.

Company Profile

Shanghai Yekun Machinery specializes in advanced hydraulic pile driving solutions. With rigorous quality management and continuous technological innovation, we deliver reliable equipment that meets the demanding requirements of modern construction projects. Our young, professional team is committed to providing comprehensive support and developing lasting partnerships with clients worldwide.
