Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity

  • Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
  • Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
  • Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
  • Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
  • Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
Place of Origin Shanghai, China
Brand Name VIBRA
Certification ISO 9001:2015
Model Number PCF-600
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 8.5 CBM
Delivery Time 7-35 days
Payment Terms T/T
Supply Ability 10 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Giant Size Sheet Pile Driving And Pulling Feature High Amount Of Centrifugal Force
Operation Pressure 30Mpa Arm Weight 880kg
Hammer Weight 3700kg Vibration Frequency 3200rpm
Centrifugal Force 905 Kn Excavator 69-78 Ton
Color Blue/Yellow/Red/White, Customized Color Available HS Code 8430100000
Material Steel, Core Materials Are All Imported Piling Depth 24 Meter
Highlight

Vibro Hammer Hydraulic Pile Driver

,

24 Meter Hydraulic Pile Driver
Leave a Message
Product Description
Hydraulic Pile Driver - 3700kg Vibro Hammer, 24m Piling Capacity
Product Description

The PCF-600 Hydraulic Pile Driver is engineered for large-scale piling projects requiring exceptional power and depth capability. With a massive 3700kg hammer weight and 905kN exciting force, this robust pile driver efficiently handles 24-meter steel sheet piles, PC piles, and steel guard cylinders. Its advanced forced lubrication system and premium components ensure maximum reliability and performance in the most demanding conditions.

Keywords
  • Pile Driver
  • Hydraulic Pile Driver
  • Vibro Hammer
  • Heavy Duty Pile Driver
  • 24m Pile Driver
  • PCF-600
  • Foundation Equipment
Key Features
  • High Power Output: Delivers 905kN exciting force for rapid pile driving
  • Extended Depth Capacity: Handles piles up to 24 meters in length
  • Advanced Lubrication System: Forced oil circulation reduces operating temperature by 20%
  • Premium Components: Features imported Parker motor and SKF bearings
  • Enhanced Durability: Q420 high-strength steel plate construction
  • Optimized Hydraulic System: Large flow confluence valve with 700L capacity
Technical Parameters
Parameter Value
Model PCF-600
Hammer Weight 3700 kg
Exciting Force 905 kN
Maximum Piling Depth 24 m
Eccentric Moment 10.5 kgm
Recommended Excavator 69-78 T
Arm Weight 880 kg
Competitive Advantages
  • Proven Host Compatibility: Perfectly matched with Caterpillar 374 and Hitachi 850 excavators
  • Rigorous Quality Control: Full running-in tests ensure optimal performance
  • Extended Component Life: Forced filtration system prolongs lubrication intervals
  • Superior Clamping System: 602KN clamping force ensures secure pile handling
  • Thermal Management: External oil circulation significantly reduces operating temperature
Frequently Asked Questions

Q: What makes your PCF-600 pile driver suitable for 24-meter piling?
A: The combination of 905kN exciting force, 3700kg hammer weight, and optimized hydraulic system provides the necessary power and stability for deep piling applications.

Q: What maintenance advantages does your lubrication system offer?
A: Our forced lubrication system features external oil circulation, forced filtration, and ensures complete bearing lubrication, extending maintenance intervals and reducing operating temperature by 20%.

Q: Are you an authorized manufacturer?
A: Yes, we have 12 years of manufacturing experience with our factory located in Suzhou, maintaining strict compliance with industry technical standards.

Q: What is your warranty policy?
A: We provide 12 months warranty from installation completion, covering mainframe and key components (excluding wearing parts).

Q: Can you customize the pile driver for specific projects?
A: Yes, we can accommodate logo customization and discuss specific project requirements to ensure optimal equipment configuration.
