200kN Pulling 60kw Hydraulic Guardrail Electric Pile Driver Machine

Place of Origin Shanghai, China
Brand Name Electric Vibrating PIle Hammer/Driver
Model Number DZ-60A
Minimum Order Quantity 1
Price Negotiable
Delivery Time 15 work days
Payment Terms L/C, T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Design Low Noise Motor Shock Resistant
Motor Power 60kw Allowable Pulling Force 200kN
Dimensions (height×length×width) 2.24 M×1.21 M×1.37 M Can Be Equipped With Fixture Single Fixture / Steel Pipe Fixture
High Light

60kw Electric Pile Driver


200kN Pile Driver machine


60kw hydraulic guardrail Pile Driver

Leave a Message
Product Description

DZ60A is currently the most widely used pile foundation construction equipment in China.

1. The equipment is designed for low noise, clean and environmentally friendly

2. The gearbox lubricating oil is a heavy-duty gear oil for German Volkswagen, which does not need to be replaced within one year under normal operation

3. The shock-resistant motor is the top domestic brand

4. High-quality after-sales service, our after-sales engineers will provide you with after-sales and technical related services at any time

Product parameter

Motor Power 60 kW
Vibration frequency 1000 R/MIN
Eccentric moment 360 Nm
Exciting force 450 kN
No-load amplitude 9.6/10 mm
Allowable pulling force 200 kN
Dimensions (height×length×width) 2.24 m×1.21 m×1.37 m
total weight 4320 kg
Can be equipped with fixture Single fixture
Generator power 200 kW
Crawler crane specifications 35 t
