PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion

  • PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion
  • PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion
  • PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion
  • PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion
  • PCF 330 Vibratory Pile Driver: Vibro Hammer, Powerful Driving & Fast Bridge Foundation Completion
Place of Origin Shanghai, China
Brand Name VIBRA
Certification ISO 9001:2015
Model Number PCF-330
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 6.2 CBM
Delivery Time 8-35 days
Payment Terms T/T,D/P,Western Union,MoneyGram,L/C
Supply Ability 15 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hydraulic Vibrating Sheet Pile Driver Feature Mini Pile Driver Suitable For Small Excavator
Material Steel, Core Materials Are All Imported Color Blue/Yellow/Red/White, Customized Color Available
Hammer Weight 2850 Kg Arm 750 Kg
Max Piling 12 Meter Vibration Frequency 3300 Rpm
Operating Pressure 32 Mpa Excavator 33-38 Ton
Centrifugal Force 420 Kn HS Code 8430100000
Highlight

PCF 330 Vibratory Pile Driver

,

12 Meter Vibratory Pile Driver

,

Bridge Pile Vibro Hammer
Leave a Message
Product Description

Keywords: Vibro Pile Driver, Bridge Pile Driver, Hydraulic Pile Driver, Vibratory Hammer, Foundation Pile Driver

Product Description

The PCF-330 Vibro Pile Driver delivers exceptional performance for bridge foundation projects. Featuring interchangeable parts with mainstream hammers and easy-maintenance box bearings, it ensures reliable operation with 420 KN centrifugal force and 3300 RPM vibration frequency for efficient pile driving.

Key Features
  • Compatible box structure with mainstream hammer specifications
  • Interchangeable spare parts for convenient maintenance
  • Fabricated box structure with premium material strength
  • Precision welding and machining processes
  • Two-stage vibration frequency control
  • Integrated import control valve system
Technical Advantages
  • High-frequency vibration (3200-3500 RPM) for optimal soil penetration
  • Powerful centrifugal force (385-585 KN) for various soil conditions
  • Maximum pile length capacity up to 21 meters
  • Compatible with 27-70 ton excavators
  • Fuel-efficient operation using excavator hydraulic system
  • Easy operation with quick learning curve
Technical Parameters
Model PCF-300 PCF-330 PCF-350 PCF-450 PCF-500
Vibration Frequency (rpm) 3500 3300 3500 3300 3200
Operation Pressure (Mpa) 32 32 32 32 32
Centrifugal Force (KN) 385 420 470 535 585
Max. Pile Length (m) 12 12 15 18 21
Hammer Weight (kg) 2750 2850 2950 3150 3350
Excavator (T) 27-30 33-38 40-45 47-55 55-70
Applications

Bridge foundation construction, municipal engineering, building foundations, cofferdam projects, and large-scale infrastructure development.

Machinery Characteristics
  • Independent control system for easy maintenance
  • Dual-pump convergence for enhanced excitation force
  • Lightweight design for flexible application
  • Cost-effective operation with minimal fuel consumption
  • Simple operation suitable for excavator operators
FAQ

Q: Are you a manufacturer?

A: Yes, we have over 12 years of manufacturing experience with our factory located in Suzhou.

Q: What is your warranty policy?

A: We offer 12-month warranty on main components from installation date.

Q: What is the minimum order quantity?

A: MOQ is 1 set.

Q: What payment methods do you accept?

A: We accept T/T and D/P payments.

Q: What is the delivery time?

A: 7-35 days to Shanghai port, plus overseas shipping time.

Q: Can you provide custom logo service?

A: Yes, we offer logo customization.

Q: How do you ensure product quality?

A: All equipment strictly complies with national technical standards for pile drivers.

Company Profile

With successful manufacturing of large models including PCF-500 for CAT 365 excavators, we maintain strict quality control in material selection, welding processes, and machining accuracy to ensure product reliability and performance stability.
