Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators

  • Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators
  • Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators
  • Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators
  • Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators
  • Efficient Operation & Long-Lasting Hydraulic Vibro Pile Hammer for 47-55T Excavators
Place of Origin Shanghai, China
Brand Name VIBRA
Certification ISO 9001:2015
Model Number PCF-450
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 5.824 CBM
Delivery Time 7-35 days
Payment Terms L/C,T/T,D/P
Supply Ability 35 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Long Sheet Pile Driver Feature Equal Piling And Pulling Efficiency
Vibration Frequency 3300 Rpm Operation Pressure 32 Mpa
Arm Weight 820 Kg Hammer Weight 3150 Kg
Centrifugal Force 535 Kn Excavator 47~55 Ton
Max. Pile Length 18 Material Steel, Core Materials Are All Imported
Color Blue/Yellow/Red/White, Customized Color Available Type Hydraulic Vibrating Hammer
HS Code 8430100000 Condition New
Highlight

Excavator Mounted Vibratory Sheet Pile Driver

,

55T Hydraulic Vibro Pile Hammer

,

Hydraulic Vibratory Sheet Pile Driver
Leave a Message
Product Description
Core Keywords

Pile Driver, Hydraulic Vibro Pile Driver, Vibratory Sheet Pile Driver, Excavator-Mounted Pile Driver, PCF Series Pile Driver

Product Overview

The PCF Series Hydraulic Vibro Pile Driver is an excavator-mounted foundation equipment highly favored by customers. With a box structure consistent with mainstream Taiwanese hammers, it features interchangeable spare parts and easy-to-maintain box bearings. We strictly control material strength, welding processes, and machining accuracy to ensure stable quality. The series covers models from PCF-300 to PCF-500, including the large PCF-500 compatible with CAT 365 excavators.

Key Features
  • Flexible & Cost-Effective: Mini and lightweight design enables flexible application. Utilizes the excavator’s hydraulic system, eliminating the need for additional driving systems, thus saving fuel and transportation costs.
  • Precise & Easy Operation: Adopts imported integrated control valves for independent control of each action, facilitating maintenance. Two-stage vibration frequency control, with the second stage using dual-pump confluence to enhance excitation force for special geology. Simple to learn, accessible to excavator operators with basic experience.
  • Reliable Structure: Fabricated box structure with high manufacturing standards. Equipped with super-heavy cast steel fixtures, enlarged oil cylinders, and connecting rods for enhanced reliability.
Competitive Advantages
  1. Strong Performance: Boasts high vibration frequency, large exciting force, and high strength of structural parts, ensuring efficient piling even in complex conditions.
  2. Premium Configuration: Core components like Rexroth vibration motors are imported from top European brands, guaranteeing stable and durable operation.
Technical Parameters
Item PCF-300 PCF-330 PCF-350 PCF-450 PCF-500
Vibration Frequency (rpm) 3500 3300 3500 3300 3200
Operation Pressure (Mpa) 32 32 32 32 32
Centrifugal Force (kn) 385 420 470 535 585
Max. Pile Length (m) 12 12 15 18 21
Arm Weight (kg) 750 750 750 820 820
Hammer Weight (kg) 2750 2850 2950 3150 3350
Matching Excavator (T) 27~30 33~38 40~45 47~55 55~70
Working Principle

The hydraulic vibro pile driver uses high-frequency vibration generated by the excavator’s hydraulic motor. It transmits vibration force to liquefy surrounding soil, break its structure, and reduce friction. Then, the excavator drives the pile into the ground. The hydraulic motor powers two eccentric shafts rotating in opposite directions—horizontal forces cancel out, while vertical forces combine to produce vertical-frequency vibration.

Frequently Asked Questions (FAQ)

Q: Are the spare parts of the PCF Series Pile Driver easy to replace?

A: Yes, the spare parts are interchangeable with those of mainstream Taiwanese hammers, ensuring convenient replacement.

Q: What makes the PCF Series suitable for special geological conditions?

A: It has two-stage vibration frequency control; the second stage adopts dual-pump confluence to significantly increase excitation force, overcoming special geology.

Q: Does the pile driver require an additional driving system?

A: No, it utilizes the excavator’s hydraulic system, eliminating the need for extra driving systems and saving costs.

Q: What is the maximum pile length the PCF Series can handle?

A: The largest model PCF-500 can drive piles up to 21 meters, while other models range from 12 to 18 meters.

Q: Is professional training required to operate this pile driver?

A: It is easy to learn. Drivers with basic excavator operation experience can master it through practice.
