47 - 55T Excavator Mounted Hydraulic Vibro Pile Hammer / Vibratory Sheet Pile Driver

Place of Origin Shanghai, China
Brand Name VIBRA
Certification ISO 9001:2015
Model Number PCF-450
Minimum Order Quantity 1 set
Price 26000 to 32000 USD
Packaging Details 5.824 CBM
Delivery Time 7-35 days
Payment Terms L/C, T/T, D/P
Supply Ability 35 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Long Sheet Pile Driver Feature Equal Piling And Pulling Efficiency
Vibration Frequency 3300 Rpm Operation Pressure 32 Mpa
Arm Weight 820 Kg Hammer Weight 3150 Kg
Centrifugal Force 535 Kn Excavator 47~55 Ton
Max. Pile Length 18 Material Steel, Core Materials Are All Imported
Color Blue/Yellow/Red/White, Customized Color Available Type Hydraulic Vibrating Hammer
HS Code 8430100000 Condition New
High Light

Excavator Mounted Vibratory Sheet Pile Driver

,

55T Hydraulic Vibro Pile Hammer

,

Hydraulic Vibratory Sheet Pile Driver

Leave a Message
Product Description

47~55T Excavator Mounted Hydraulic Vibro Pile Hammer/Vibratory Sheet Pile Driver



Description



This series of machines are very popular with customers. The structure of the box body is consistent with that of the mainstream Taiwan hammer. The spare parts are interchangeable. The box bearing is easy to be maintained. The fabricated box structure has higher requirements for material strength, welding process and machining accuracy. We have strict control in all aspects of manufacturing to ensure stable quality.

We have successfully manufactured the largest model PCF-500 which matches with CAT 365 excavator.



Equipment Advantage

  • The vibration frequency is high, the exciting force is large, and the strength of each structural part is high
  • Super heavy cast steel fixture, enlarged oil cylinder and connecting rod, high reliability
  • The whole machine configuration is high, and the core parts Rexroth vibration motor are imported from fist-line European brands.

Technical Parameter



                 Item                        Model PCF-300 PCF-330 PCF-350 PCF-450 PCF-500
Vibration Frequency rpm 3500 3300 3500 3300 3200
Operation Pressure Mpa 32 32 32 32 32
Centrifugal Force kn 385 420 470 535 585
Max. Pile Length m 12 12 15 18 21
Arm Weight kg 750 750 750 820 820
Hammer Weight kg 2750 2850 2950 3150 3350
Excavator T 27~30 33~38 40~45 47~55 55~70





Working Principle



Hydraulic vibrating pile driver take the advantage of high frequency vibration generated by motor and transit the vibration force to the hydraulic vibrating pile driver for the surrounding soil liquefying & break its structure to reduce the friction; then piling or drilling the pile form the soil ground via excavator. The high frequency vibration is driven by the hydraulic motor of the excavator.

The hydraulic motor drives the two eccentric axes to rotate at high speed in opposite direction. The horizontal force of the eccentric axis cancels each other without vibration. The vertical forces add up to each other, creating a vertical-frequency vibration.



Machinery Characteristics

  • The control system adopts integrated import control valve, each action can be controlled independently, convenient for maintenance and check.
  • The vibration frequency is controlled at two stages, and the second stage vibration is the confluence of double pumps, which greatly increases the excitation force and overcomes the special geology.
  • Mini and light weight design make application flexible.
  • Taking the advantage of the excavator hydraulic system without other driving system requirement, which save fuel oil and transportation cost.
  • The operation is simple and easy to learn. The driver who has the operation foundation of excavator can operate it with practice
