Product Details
Name Photovoltaic Pile Driving Equipment Feature High Construction Efficiency
Arm Weight 500kg Operation Pressure 32Mpa
Hammer Weight 1900kg Vibration Frequency 2800rpm
Centrifugal Force 335KN Excavator 20-30T
Max Piling Depth 12 Meter Material Steel, Core Materials Are All Imported
Type Hydraulic Vibrating Hammer Condition New And Used Both Available
Color Blue/Yellow, Customized Color Available HS Code 84301000
Highlight

Solar Vibro Hammer Sheet Pile

,

Construction Projects Vibratory Pile Hammer

,

32Mpa Hydraulic Press Pile Machine
Leave a Message
Product Description

Product Introduction: VIBRA Hydraulic Pile Drive Hammer

Core Keywords: Pile Drive Hammer, Hydraulic Vibratory Hammer, Sheet Pile Driver, PV Pile Hammer, Vibratory Pile Driver

Product Overview

The VIBRA Hydraulic Pile Drive Hammer represents advanced piling technology that excels in various foundation projects. Utilizing high-frequency vibration to liquefy surrounding soil and reduce friction, this equipment enables efficient pile driving and extraction. Specially developed for the rapidly growing photovoltaic industry, our specialized models overcome traditional limitations to deliver superior performance with enhanced cost-effectiveness.

Key Features

  • High-frequency vibration system (2500-3200 RPM)
  • 180° pile clamping and rotation capability
  • Two-stage vibration frequency adjustment
  • Double-pump excitation force enhancement
  • Rubber sheath noise reduction technology
  • Multi-functional pile compatibility

Product Advantages

  • Versatile Application: Suitable for sheet piles, concrete piles, H-beams, steel rails, and pipe piles
  • Environmental Friendly: Low-noise operation with minimal vibration transmission
  • Damage Prevention: Protects pile integrity during installation and extraction
  • Fuel Efficiency: Utilizes excavator hydraulic system without additional power requirements
  • Quick Operation: Fast conversion between driving and extraction modes
  • Space-Safe: Operates safely near existing structures without causing damage

Technical Parameters

Model Vibration Frequency Centrifugal Force Max Pile Length Hammer Weight Compatible Excavator
FV-250 2500 RPM 265 KN 10 m 1700 kg 20-30 T
FV-280 2800 RPM 335 KN 12 m 1900 kg 20-30 T
FV-300 3200 RPM 350 KN 12 m 2100 kg 30-35 T
FV-350 3200 RPM 455 KN 15 m 2600 kg 40-45 T
FV-400 3200 RPM 485 KN 18 m 2700 kg 45-60 T

Working Principle

The pile drive hammer employs high-frequency vibration generated by hydraulic motors, transmitting mechanical energy to the pile body. This creates vertical vibration that liquefies surrounding soil, significantly reducing frictional resistance. The synchronized rotation of dual eccentric axes produces powerful vertical force while canceling horizontal vibrations, enabling smooth pile installation and extraction using the excavator's hydraulic power.

Frequently Asked Questions

Q: What is the warranty period?

A: 12-month warranty from installation completion, covering main components (excluding wear parts).

Q: What is the minimum order quantity?

A: MOQ is 1 set.

Q: What payment methods do you accept?

A: We accept T/T and D/P payments.

Q: What is the delivery timeline?

A: 7-35 days to Shanghai Port, plus overseas shipping time.

Q: Can we add our company logo?

A: Yes, OEM logo customization is available.

Q: How is product quality ensured?

A: All equipment strictly follows "Technical Conditions for Pile Driver Enterprises" standards.

Q: How to place an order?

A: Contact us with requirements → Receive proforma invoice → Confirm order → Production → Delivery tracking.

About YeKun Construction Machinery

As a technology-oriented enterprise, YeKun Construction Machinery specializes in manufacturing high-speed hydraulic pile driving equipment. The VIBRA brand has gained rapid market recognition through superior product quality and innovative solutions. With a young, professional team and customer-focused approach, we continuously strive to become the most reliable and comprehensive supplier of vibration pile machinery and services in the global market.
