Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility

  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
  • Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility
Place of Origin SHANGHAI
Brand Name VIBRA
Model Number FV-330
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details 5.824 CBM
Delivery Time 7-35 days
Payment Terms L/C,T/T,D/P
Supply Ability 15 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Concrete Pile Driving Equipment Feature High Strength
Vibration Frequency 3200rpm Operation Pressure 32Mpa
Centrifugal Force 372KN Max.Pile Length 12m
Arm Weight 670kg Hammer Weight 2300kg
Excavator 33~40Ton Color Blue/Yellow, Customized Color Available
Material Steel, Core Materials Are All Imported HS Code 8430100000
Type New And Used Both Available
Highlight

12m Concrete Pile Driving Equipment

,

12m hydraulic vibratory hammer

,

Concrete Pile hydraulic vibratory hammer
Leave a Message
Product Description

VIBRA Hydraulic Pile Driver: Advanced Piling Solutions for Modern Construction

Product Overview
The VIBRA Hydraulic Pile Driver represents the pinnacle of vibratory piling technology, combining powerful performance with exceptional versatility. Designed for various foundation projects, our pile drivers deliver superior efficiency in driving, extracting, and soil compaction applications. With advanced hydraulic systems and precision engineering, VIBRA equipment ensures reliable performance across multiple construction scenarios.

Key Features

  • Multi-speed control system for optimized operation

  • Compatible with sheet piles, concrete piles, and steel casing piles

  • Advanced hydraulic system with high power and flow capacity

  • Compact design for easy transportation and quick setup

  • Low noise and vibration technology for urban environments

  • Non-damage pile driving technology

Technical Advantages

  • High vibration frequency (2500-3200 rpm) for superior performance

  • Powerful centrifugal force (265-485 KN) for efficient pile driving

  • Wide compatibility with 20-60 ton excavators

  • Maximum pile length capacity up to 18 meters

  • Precision engineering for minimal maintenance requirements

Applications

  • Bridge and highway construction

  • Municipal engineering projects

  • Building foundation work

  • Marine and port construction

  • Cofferdam and retaining walls

  • Urban construction in noise-sensitive areas

Technical Parameters

Efficient 2.3T Pile Driver: Handles 12m Concrete Piles with High Versatility 0



Company Profile
Shanghai YeKun Construction Machinery Co., Ltd. specializes in manufacturing high-quality vibratory piling equipment. With our VIBRA brand gaining rapid market recognition, we have achieved remarkable annual growth through our commitment to technological innovation and customer satisfaction. Our young, dynamic team is dedicated to becoming the most reliable and professional supplier in the vibration piling equipment industry.

Frequently Asked Questions

Q: What is the warranty coverage?
A: We provide 12 months warranty from installation completion date, covering mainframe and key components (excluding wear parts).

Q: What is your minimum order quantity?
A: MOQ is 1 set, making it convenient for all project requirements.

Q: Which payment methods do you accept?
A: We accept T/T and D/P payments for all orders.

Q: What is your delivery timeline?
A: Standard delivery time is 7-35 days to Shanghai Port, with additional shipping time for overseas destinations.

Q: Do you offer logo customization?
A: Yes, we provide custom logo services according to client requirements.

Q: How do you ensure product quality?
A: All equipment strictly complies with "Technical Conditions for Pile Driver Enterprises" standards.

Q: Do you welcome dealership applications?
A: We actively seek qualified dealers and look forward to developing strategic partnerships for regional market development.
