3200rpm Concrete Pile Driver For Many Fields Engineering Construction

Place of Origin SHANGHAI
Brand Name VIBRA
Model Number FV-350
Minimum Order Quantity 1 set
Price 26000 to 32000 USD
Packaging Details 7.14
Delivery Time 7-35 days
Payment Terms L/C, T/T, D/P
Supply Ability 35 set/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Concrete Pile Driving Equipment Feature Low Vibration
Vibration Frequency 3200rpm Operation Pressure 32Mpa
Centrifugal Force 455KN Max.Pile Length 15m
Arm Weight 750kg Hammer Weight 2600kg
Excavator 40~45T
High Light

concrete pile driver

,

concrete pile driving machine

Leave a Message
Product Description


Description

Hydraulic vibration prefabricated pipe pile driver, is the use of vibration-type pile piling, especially for municipal, bridges, cofferdam, building foundation and other short pile project.

Features


  • Fast construction speed, wide range of working geology, and widely used in many fields of engineering construction at home and abroad.
  • Environmental protection type: low vibration and noise during construction, not disturbing the residents.
  • Novel design, small volume and convenient transportation.
  • Powerful and multiple function: Applied to various types of steel sheet piles, steel casing piles, vibro driven cast-in-place piles, surface compaction, deep compaction and cast-in-place thin-walled pile construction; also be used as PHC pile, steel sheet pile and steel casing.
  • Application range: widely used in municipal, water conservancy, construction, bridge, wharf, marine engineering and other pile foundation construction.
  • Main application fields of hydraulic vibration hammer at present: Steel sheet pile engineering, road and bridge engineering construction, vibration compaction construction, rotary pile driver construction, sinking pipe cast-in-place pile foundation construction, concrete sheet pile construction, offshore pile construction, pile foundation construction in sensitive areas, etc.
  • Permanent projects: wharf, water conservancy dike revetment, retaining wall, retaining wall, breakwater, diversion dike, dock, gate; offshore pile foundation construction, road and bridge engineering, civil construction, municipal engineering, water conservancy engineering, etc.
  • Temporary projects: Mountain sealing, temporary bank expansion, cut-off, bridge and cofferdam construction, earth retaining, water retaining and sand retaining for excavation of temporary ditches for large-scale pipeline laying; it can also be used for flood control, collapse prevention and quicksand prevention.

3200rpm Concrete Pile Driver For Many Fields Engineering Construction 0

Technical Parameter


Item FV-250 FV-280 FV-300 FV-330 FV-350L FV-350 FV-400
Vibration Frequency  (rpm) 2500 2800 3200 3200 3200 3200 3200
Operation Pressure  (Mpa) 30 32 32 32 32 32 32
Centrifugal Force  (KN) 265 335 350 372 435 455 485
Max.Pile Length (m) 10 12 12 12 15 15 18
Arm Weight  (kg) 500 500 670 670 670 750 750
Hammer Weight  (kg) 1700 1900 2100 2300 2400 2600 2700
Excavator  (T) 20-30 20-30 30-35 33-40 35-40 40-45 45-60


3200rpm Concrete Pile Driver For Many Fields Engineering Construction 1

About Us

Shanghai Yekun Construction Machinery Co., Ltd. was founded in 2014, A professional company involving in hydraulic vibrating pile driver manufacture, sale and service. Our company take the latest high speed hydraulic vibrating pile driver and its components as the main products. Our products vastly apply for infrastructure & construction industries.

We focus on product quality with the latest industrial technology. The mini hydraulic vibrating pile driver lead the industrial trend. The middle and large hydraulic vibrating pile driver also are highly recognized by our clients. At the same time, we actively cooperated with the engineering machinery factory and construction company to jointly develop more functional professional equipment, and we hired foreign professionals as our technical adviser.

Our company is consisting of a young, enthusiasm professional team. Adhere to client as priority, Quality as first concern, Management as foundation. We are working for the direction to become the most professional and comprehensive hydraulic vibrating pile driver manufacture and service supplier.

3200rpm Concrete Pile Driver For Many Fields Engineering Construction 2

FAQ

Q: How long is the warranty period ?

A: The warranty period is 12 months from the date of completion of installation, the mainframe and key components, except for wearing parts.

Q: What is the MOQ ?

A: One set is available.

Q: What's the payment method ?

A: We accept L/C, T/T and D/P payment.

Q: What is the delivery time ?

A: The delivery time is generally 1-8 days, and arrive at Shanghai Port. Shipping time should be considered overseas.

Q: Can I have our LOGO on the machine ?

A: Of course you can.

Q: How is your product quality ?

A: Our equipment is strictly implemented in accordance with the technical standards of "Technical Conditions for Pile Driver Enterprises".

Q: Can I be your dealer ?

A: Welcome to become our dealer, and we are looking forward to further developing into a regional general agent and strategic partner like you with lofty ideals!
