470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator

470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator
470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator

Large Image :  470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator

Product Details:
Place of Origin: Shanghai, China
Brand Name: VIBRA
Model Number: PCF-350
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 22000 to 32000 USD
Delivery Time: 7-35 days
Payment Terms: L/C, T/T
Supply Ability: 15 set/month
Detailed Product Description
Frequency: 3500 Rpm Pressure: 32 Mpa
Centrifugal Force: 470 Kn Maximum Pile: 15 M
Weight Of Arm: 750 Kg Weight Of Hammer: 2950 Kg
Excavator Operating Weight: 40~45 T
High Light:

470Kn sheet pile driver for excavator

,

3 Ton Hydraulic Pile Driver

,

470Kn sheet piling attachment for excavator

About Us

Shanghai Yekun Construction Machinery Co., Ltd. is a particular endeavor picking up reasonable involvement with the creation, arrangements and organization of vibratory pile driver and extractor. Its things are prevalently quick pile driver and its enveloping embellishments. The stuff is extensively used in various kinds of structure advancement. After a respectably short season of progress, the association has won the affirmation of customers and achieved the twofold improvement of yearly arrangements. VIBRA brand promoting cross country and conveyed abroad. In May 2019, Yekun Construction Machinery (Suzhou) Co ., Ltd. was set up as another collecting base with a yearly constraint of 300 units.



Product Details



This course of action of machines are standard with customers. The structure of the case body is dependable with that of the standard Taiwan hammer. The additional parts are replaceable. The compartment bearing is broken and easy to be kept up. The made box structure has higher necessities for material strength, welding measure and machining accuracy. We have extreme control in all pieces of amassing to ensure stable quality. We have viably manufactured the greatest model pcf-500, which matches with Cat 365.



Item Model PCF-300 PCF-330 PCF-350 PCF-450 PCF-500
Vibration Frequency rpm 3500 3300 3500 3300 3200
Operation Pressure Mpa 32 32 32 32 32
Centrifugal Force kn 385 420 470 535 585
Max. Pile Length m 12 12 15 18 twenty one
Arm kg 750 750 750 820 820
Hammer kg 2750 2850 2950 3150 3350
Excavator T 27~30 33~38 40~45 47~55 55~70





Equipment Advantage



  • The vibration repeat is high, the stimulating force is huge, and the strength of each fundamental part is high
  • Extremely profound cast steel mechanical assembly, expanded oil chamber and interfacing bar, high trustworthiness
  • The whole machine course of action is high, and the focal points of Rexroth vibration motor are imported first-line brands



470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator 0



Application scope



By assisting different clasps, it can sink and pull out heap of wood, solid pile, steel sheet pile, steel pipe pile, H-shaft steel, steel shield, etc
Essentially any 6-60 ton excavator of any brand can be used for piling
It is for the most part used in stream bank, house foundation, metropolitan association, interface, photovoltaic pile and various foundations advancement fields



470Kn Centrifugal Force 3 Ton Hydraulic Pile Driver For Excavator 1

FAQ



Q: How long is the warranty period?

A: The warranty period is 12 months from the date of completion of installation, the mainframe and key components, except for wearing parts.



Q: What is the MOQ?

A: One set is available.



Q: What's the payment method?

A: We accept L/C, T/T and D/P payment.



Q: What is the delivery time?

A: The delivery time is generally 7-35 days, and arrive at Shanghai Port. Shipping time should be considered overseas.



Q: Can I have our LOGO on the machine?

A: Of course you can.



Q: How is your product quality?

A: Our equipment is strictly implemented in accordance with the technical standards of "Technical Conditions for Pile Driver Enterprises".



Q: Can I be your dealer?

A: Welcome to become our dealer, and we are looking forward to further developing into a regional general agent and strategic partner like you with lofty ideals!
