Pile Driver - Amphibious Operation for Sheet Piling

  • Pile Driver - Amphibious Operation for Sheet Piling
  • Pile Driver - Amphibious Operation for Sheet Piling
  • Pile Driver - Amphibious Operation for Sheet Piling
  • Pile Driver - Amphibious Operation for Sheet Piling
  • Pile Driver - Amphibious Operation for Sheet Piling
  • Pile Driver - Amphibious Operation for Sheet Piling
Place of Origin SHANGHAI
Brand Name VIBRA
Model Number FV-150
Minimum Order Quantity 1
Price Negotiation
Packaging Details 4 CBM
Delivery Time 8-35 work days
Payment Terms L/C,T/T,D/P
Supply Ability 15 Set/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Mini Pile Driver For Water Areas Feature Suitable For Using In Watercourse
Vibration Frequency 2500rpm Operation Pressure 30Mpa
Centrifugal Force 172KN Max.Pile Length 8m
Arm Weight 160kg Hammer Weight 1100kg
Excavator 12-17 Ton
Highlight

Amphibious sheet electric pile driver

,

Water Amphibious mini pile driver

,

Amphibious static pile driver
Leave a Message
Product Description
Product Introduction: Amphibious Hydraulic Vibrating Pile Driver
1. Core Keywords

Amphibious Pile Driver, Hydraulic Vibrating Pile Driver, FV-100 Pile Driver, FV-150 Pile Driver, Steel Sheet Pile Driver, Flood Disaster Recovery Pile Driver, Wetland/Coastal Construction Pile Driver

2. Product Overview & Application Scenarios

Common perception links amphibious pile drivers solely to vast wetlands, but their utility extends far beyond this. Designed for high efficiency and cost savings, this hydraulic vibrating pile driver excels in water-rich and complex terrains, making it ideal for:

  • Coastal and ocean-side projects
  • River bed construction
  • Flood-prone area development
  • Specialized tasks: flood/disaster recovery, dredging, environmental remediation
  • Infrastructure projects: pipeline laying, levee building, and highway construction
3. Product Features
  • Compact & Lightweight Design: Boasts a super-small structure and light weight, ensuring easy maneuverability even in narrow spaces.
  • Powerful Vibration Performance: Delivers maximum vibration force, enabling efficient pile driving and pulling operations.
  • Fourth-Generation Upgrade: Features a more reasonable mechanical structure, enhancing the overall stability of the machine during operation.
  • Versatile Application: Suitable for construction in small river channels and house foundations; capable of driving and pulling steel sheet piles, cement piles, and wood piles.
4. Technical Parameters
Item FV-100 Model FV-150 Model
Vibration Frequency 2500 rpm 2500 rpm
Operation Pressure 30 Mpa 30 Mpa
Centrifugal Force 117 KN 172 KN
Maximum Pile Length 6 m 8 m
Arm Weight 160 kg 260 kg
Hammer Weight 850 kg 1100 kg
Matching Excavator 7-12 T 12-17 T
5. Frequently Asked Questions (FAQ)
Q1: What is the warranty period for the amphibious pile driver?

A1: The warranty period is 12 months from the date of installation completion, covering the mainframe and key components (excluding wearing parts).

Q2: What is the Minimum Order Quantity (MOQ)?

A2: The MOQ is 1 set—we accept single-unit orders to meet your specific needs.

Q3: What payment methods do you accept?

A3: We support T/T (Telegraphic Transfer) and D/P (Documents against Payment) for secure transactions.

Q4: How long is the delivery time?

A4: The production and delivery cycle is generally 7–35 days, with delivery to Shanghai Port. For overseas orders, additional shipping time should be considered.

Q5: Can we customize the machine with our own LOGO?

A5: Yes, we offer LOGO customization services to meet your branding requirements.

Q6: How do you ensure product quality?

A6: All our pile drivers are strictly manufactured and inspected in accordance with the technical standards outlined in Technical Conditions for Pile Driver Enterprises.

Q7: Is it possible to become your dealer?

A7: We warmly welcome partners to join us as dealers. We also look forward to developing long-term collaborations with ambitious partners to become regional general agents and strategic partners.
