Vibratory Pile Driver - Heavy Duty for Mini Excavators

  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
  • Vibratory Pile Driver - Heavy Duty for Mini Excavators
Place of Origin SHANGHAI
Brand Name VIBRA
Certification ISO 9001:2015
Model Number FV-150
Minimum Order Quantity 1
Price Negotiation
Packaging Details 4 CBM
Delivery Time 7-35 work days
Payment Terms L/C,T/T,D/P
Supply Ability 15 Set/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Mini Pile Driver Feature Light Weight
Vibration Frequency 2500rpm Operation Pressure 30 Mpa
Centrifugal Force 172KN Max.Pile Length 8m
Arm Weight 260kg Hammer Weight 1100kg
Material Steel, Core Materials Are All Imported Type New And Used Both Available
Color Blue/Yellow, Customized Color Available HS Code 84301000
Highlight

2500rpm vibratory pile driver for excavator

,

30Mpa Mini Excavator Pile Driver

,

30Mpa excavator mounted pile driver
Leave a Message
Product Description
Product Name: VIBRA Hydraulic Vibratory Pile Driver

Core Keywords: pile driver, hydraulic pile driver, vibratory pile driver, excavator pile driver, construction pile driver, VIBRA pile driver

Product Overview

The VIBRA Hydraulic Vibratory Pile Driver represents advanced engineering in modern foundation equipment. Utilizing high-frequency vibration technology, this innovative machine transforms standard excavators into efficient piling systems. Through sophisticated soil liquefaction technology, it significantly reduces frictional resistance during pile installation and extraction, making it an ideal solution for various construction projects requiring precision and efficiency.

Working Principle

The VIBRA system employs high-frequency vibration transmitted vertically to the pile body, causing structural changes in surrounding soil that lead to strength reduction and liquefaction. This process minimizes side friction between the pile and soil, enabling smooth penetration using the combined force of excavator down pressure, hammer vibration, and pile weight. During extraction, the same vibration principle facilitates easy pile removal with excavator lift power, with all parameters precisely controlled according to specific site conditions.

Key Features
  • High-frequency vibration system (2500-2800 RPM)
  • Advanced hydraulic control technology
  • Precision engineering for optimal performance
  • Robust construction for durability
  • Quick-connect excavator compatibility
  • Adaptive power control system
Product Advantages
  1. Efficient Operation: High-speed vibration enables rapid pile driving and extraction
  2. Soil Adaptation: Effective in various soil conditions and moisture levels
  3. Reduced Friction: Liquefaction technology minimizes soil resistance
  4. Versatile Application: Suitable for multiple pile types and construction scenarios
  5. Precision Control: Adjustable parameters for different project requirements
  6. Reliable Performance: Proven technology with consistent results
Technical Specifications
Parameter FV-100 FV-150
Vibration Frequency 2500 rpm 2800 rpm
Operating Pressure 30 MPa 32 MPa
Centrifugal Force 117 kN 172 kN
Max Pile Length 6 m 8 m
Arm Weight 160 kg 260 kg
Hammer Weight 850 kg 1100 kg
Suitable Excavator 7-12 T 12-17 T
Frequently Asked Questions

Q: How does the vibration technology improve pile driving efficiency?

A: The high-frequency vibration causes soil liquefaction around the pile, significantly reducing friction and enabling faster, more efficient pile installation with less energy consumption.

Q: What types of construction projects is this equipment suitable for?

A: Our pile driver is ideal for various foundation engineering projects including building construction, infrastructure development, and all applications requiring efficient pile driving and extraction.

Q: What is your warranty and delivery policy?

A: We provide 12-month warranty on main components with delivery within 7-35 days to Shanghai port. Minimum order quantity is one set with flexible payment options.

Q: Can we request custom branding on the equipment?

A: Yes, we can incorporate your logo and provide customized solutions based on specific project requirements and technical specifications.

Q: How do we proceed with ordering?

A: The ordering process involves: 1) Specification submission 2) Proforma invoice review 3) Order confirmation with deposit 4) Production monitoring 5) Shipment tracking until delivery.

Why Choose VIBRA
  • Advanced vibration technology for superior performance
  • Strict quality control following industry standards
  • Continuous product improvement and innovation
  • Comprehensive customer support services
  • Growing global recognition and market presence
  • Young, dynamic team committed to excellence
